Combination Gas Generator

.
Salient Features

• Modular & Compact Design

• Automatic Operation

• Energy Efficient

• High Reliability

• Low Noise

• Low Operation Cost

• Suitable for most of the application


Nitrogen / Air Generator

The specially designed generator continuously produces Nitrogen and Air of required flow, pressure and quality which is suitable for GC, Analyzer and many other applications The impurities like moisture, hydrocarbon, carbon dioxide, carbon monoxide, and particulates are removed by different methods of purification using a very high grade of molecular sieves, catalysts and filtration materials. All necessary safety and interlocks are provided with the system for smooth and unattended operation.

Technical Specifications – MGS/NZA3000

Description
Model No.                                              MGS/NZA3000
Capacity                N2 0 -                      5000 ml/min
                                Air 0 -                      5000 ml/min
Purity                      N2                            99.999%
                                Air                            79% N2 + 21% O2 ( Methane – 0.1ppm)
Pressure                                               0 – 100 Psig
Temperature                                        5 – 60 Deg C
Power Requirement                           230 VAC, 1 Ph, 50 Hz
Dew Point.                                            (-) 40 deg C
Generator Size (cm)                           78 x 68 x 60
Weight (Kg)                                           50 Kg
Compressor                                        ----------------------- Oil Free ----------------------
*** Specification may change for better performance or convenience without prior information
***** Further information on request.
